Receivers available: AD4Q (4CH), AD4D (2CH)
Transmitters available:
AD2 Handheld with KSM8, SM58, Beta58A, or Beta87A mic capsule
AD1 Beltpack with headset microphones or 1/4" input cable
System Features:
Frequency Band: G57, 470-608 MHz
Dante and AES capable
IR sync to receiver
Low/Hi power RF transmit
On/Off switches
Frequency and power lock out
Metal construction
Backlit LCD screen
AD4Q/ AD4D Features:
Output: XLR balanced per channel, 1/4" monitor
Networking: Ethernet and USB2
Ground lift and mic/line switch
Squelch and RF LED indicators
Net Weight: 5.1 kg (11.2 lbs)
2 x 1/2 whip antennae included
UA600 Antenna front panel connection kit included
Antenna combiners, helical and active directional antennas, and custom racking available upon request
AD1 Features:
Connector: TA4M
Gain adjustment: -20 dB to +35 dB
Belt clip
Batteries: 2 x AA, or rechargeable Lithium ion packs available
Net weight: 0.1 kg (0.2 lbs)
Shure WA302 1/4" instrument adapter available
AD2 Features:
RF transmit Gain adjustment: -10 dB to +20 dB
Batteries: 2 x AA or rechargeable Lithium ion packs available
Net weight: 0.4 kg (0.8 lbs)
